• Type : Ultraviolet and Infrared, Outdoor, Explosion-proof
• Nominal sensing range : 30m
• Sensing angle : 100°, Cone type
• Operating temp. : -40 ~+85℃
• Keeping temp. :-50~+90℃
• Humidity : 0~95%
• Output signal
  › Relay
    Fire : 1A ( 250VAC, 30VDC ), A-B connect point
    Error : 1A ( 250VAC, 30VDC ), A-B connect point
  › 4~20mA
  › RS485
• Fuction
  › Diagnostic sensor fault enable - Self test
  › Remote self diagnostic ON/OFF control ( BIT )


• Material : Aluminum 6061
• Surface : Anodizing Process
• Color : White silver
• Weight : About 0.53kg
• External : 64 × 64 × 75mm, Hexahedral, Connector 1/2 inch PF


• Power Cunsumption : 5.8W
• Voltage : DC 24V, ( 17~30V, pulsating current enable)
• Current
  › Idel(Sensing) :100mA
  › Fire(Activating, Emergency)(Sensing) : 120mA
  › Self test : 170mA
