Specification

• Type : Ultraviolet and Infrared
• Detection Range : 100ft(30m(FM), 15m(KFI)) for N-Heptane fire
• Field of View : Horizontal 90°, Vertical 90°
• Temperature Range Operating : -40℃ to +75℃
• Storage : -50℃ to +80℃
• Humidity Range : 0 to 95% relative humidity
• Explosion proof :
  › Class I Division 1 Groups B,C and D(FM)
  › Class II Division 1 Groups E,F and G(FM)
  › Class III (FM)
  › Ex db IIB+H2 T6(ATEX, KGS)
• Output
  › Relay
    - Fire Alarm, Fault Alarm, Warning Alarm
    - From A or B Selectable, 28vdc, 2A
  › 4-20mA
  › RS-485

***STRUCTURE

• Dimensions : W134 x H117 x D120 (mm)
                     W5.3 x H4.6 x D4.7 (inch)
• Enclosure Material : Stainless steel 316
• Shipping Weight : 3.4 kg
• Color : Metal
• Conduit Entry Size : 2 x 1/2 inch PF

**ELECTRICAL
• Operating Voltage : Typical DC24V (17 to 32)
• Power Consumption : 1.8W maximum at 32 vdc
• Wiring : 14AWG(2.08mm2) to
               24AWG(0.205mm2) shield
               cable recommended.
• Electromagnetic Compatibility : EMC Protected
